Shonky


Whether you’re a seasoned dirt jumper or just learning to cruise your neighborhood pumptrack, the Shonky is the perfect weapon of choice for the jibby side of biking. A butted cromoly frame with a 100mm travel fork provides just enough suspension to save your wrists. Fast-rolling tires help you whip corners like you’re on rails. From learning how to pump those first turns to hitting the biggest lines at the jump park, there’s nothing quite like a Shonky to ensure a good time every time.


SKU: B36SHOWHFAS — Short
SKU: B36SHOWHFAL — Long

SPECS & GEOMETRY

SPECIFICATIONS

Frame Material Kona Cromoly Butted
Sizes Short, Long
Rear Shock n/a
Fork Manitou Circus Expert 100mm Tapered 110mm Spacing
Crankarms Samox Dirt Jumper
Chainrings 28t
B/B Samox Dirt Jumper
Pedals n/a
Chain SRAM PC1
Cassette Joytech Single Speed 14t
Chainguide n/a
F/D n/a
R/D n/a
Shifters n/a
Brake Calipers Tektro HD-M275
Front Brake Rotor Tektro TR160mm
Rear Brake Rotor Tektro TR160mm
Brake Levers Tektro HD-M275
Headset FSA Orbit 1.5B ZS
Handlebar Kona XC/BC 35
Stem Kona XC/BC 35
Seatpost Kona Thumb
Seat Clamp Kona Clamp
Grips Kona Key Grip
Saddle Kona Dirt Jump
Front Hub Formula 110x20mm
Rear Hub Formula 142x12mm
Spokes Stainless Black 14g
Rims WTB ST i30 TCS 2.0
Front Tire Maxxis DTH EXO TR DUAL 26x2.3"
Rear Tire Maxxis DTH EXO TR DUAL 26x2.3"
Paint Color Satin Bone w/ Raised Decals
All specifications are subject to change without notice.

GEOMETRY

  Size S L
1 ST Length 347 347
2 TT Length 611 624
3 Reach 415 428
4 Stack 584 584
5 Standover 680 677
6 HT Angle 69.0 69.0
7 HT Length 120 120
8 ST Angle 71.5 71.5
9 CS Length 400 400
10 BB Drop 26 26
11 BB Height 307 307
12 Wheelbase 1074 1087
13 Front Center 675 688
14 Fork Length 492 492
15 Fork Offset 42 42
Bike Geometry
